Blind and robust reconstruction of adaptive optics point spread functions for asteroid deconvolution and moon detection

Initially designed to detect and characterize exoplanets, extreme adaptive optics systems (AO) open a new window on the solar system by resolving its small bodies. Nonetheless, despite the always increasing performances of AO systems, the correction is not perfect, degrading their image and producing a bright halo that can hide faint and close moons. Using a reference point spread function (PSF) is not always sufficient due to the random nature of the turbulence. In this work, we present our method to overcome this limitation. It blindly reconstructs the AO-PSF directly in the data of interest, without any prior on the instrument nor the asteroid's shape. This is done by first estimating the PSF core parameters under the assumption of a sharp-edge and flat object, allowing the image of the main body to be deconvolved. Then, the PSF faint extensions are reconstructed with a robust penalization optimization, discarding outliers on-the-fly such as cosmic rays, defective pixels and moons. This allows to properly model and remove the asteroid's halo. Finally, moons can be detected in the residuals, using the reconstructed PSF and the knowledge of the outliers learned with the robust method. We show that our method can be easily applied to different instruments (VLT/SPHERE, Keck/NIRC2), efficiently retrieving the features of AO-PSFs. Compared with state-of-the-art moon enhancement algorithms, moon signal is greatly improved and our robust detection method manages to discriminate faint moons from outliers.

Open loop calibration and closed loop non-perturbative estimation of the lateral errors of an adaptive optics system: examples with GRAVITY+ and CHARA experimental data

Performances of an adaptive optics (AO) system are directly linked with the quality of its alignment. During the instrument calibration, having open loop fast tools with a large capture range are necessary to quickly assess the system misalignment and to drive it towards a state allowing to close the AO loop. During operation, complex systems are prone to misalignments (mechanical flexions, rotation of optical elements, etc.) that potentially degrade the AO performances, creating a need for a monitoring tool to tackle their driftage. In this work, we first present an improved perturbative method to quickly assess large lateral errors in open loop. It uses the spatial correlation of the measured interaction matrix of a limited number of 2D spatial modes with a synthetic model. Then, we introduce a novel solution to finely measure and correct these lateral errors via the closed loop telemetry. Non-perturbative, this method consequently does not impact the science output of the instrument. It is based on the temporal correlation of 2D spatial frequencies in the deformable mirror commands. It is model-free (no need of an interaction matrix model) and sparse in the Fourier space, making it fast and easily scalable to complex systems such as future extremely large telescopes. Finally, we present some results obtained on the development bench of the GRAVITY+ extreme AO system (Cartesian grid, 1432 actuators). In addition, we show with on-sky results gathered with CHARA and GRAVITY/CIAO that the method is adaptable to non-conventional AO geometries (hexagonal grids, 60 actuators).

Blind and robust estimation of adaptive optics point spread function and diffuse halo with sharp-edged objects

Context . Initially designed to detect and characterise exoplanets, extreme adaptive optics (AO) systems open a new window onto the Solar System by resolving its small bodies. Nonetheless, their study remains limited by the accuracy of the knowledge of the AO-corrected point spread function (AO-PSF) that degrades their image and produces a bright halo, potentially hiding faint moons in their close vicinity. Aims . To overcome the random nature of AO-PSFs, I aim to develop a method that blindly recovers the PSF and its faint structured extensions directly into the data of interest, without any prior on the instrument or the object's shape. The objectives are both to deconvolve the object and to properly estimate and remove its surrounding halo to highlight potential faint companions. Methods . My method first estimated the PSF core via a parametric model fit, under the assumption of a sharp-edged flat object. Then, the resolved object and the PSF extensions were alternatively deconvolved with a robust method, insensitive to model outliers, such as cosmic rays or unresolved moons. Finally, the complex halo produced by the AO system was modelled and removed from the data. Results . The method is validated on realistic simulations with an on-sky AO-PSF from the SPHERE/ZIMPOL instrument. On real data, the proposed blind deconvolution algorithm strongly improves the image sharpness and retrieves details on the surface of asteroids. In addition, their moons are visible in all tested epochs despite important variability in turbulence conditions. Conclusions . My method shows the feasibility of retrieving the complex features of AO-PSFs directly from the data of interest. It paves the way towards more precise studies of asteroid surfaces and the discovery and characterisation of Solar System moons in archival data or with future instruments on extremely large telescopes with ever more complex AO-PSFs.

Estimation of the lateral mis-registrations of the GRAVITY + adaptive optics system

Context. The GRAVITY+ upgrade implies a complete renewal of its adaptive optics (AO) systems. Its complex design, featuring moving components between the deformable mirrors and the wavefront sensors, requires the monitoring and auto-calibrating of the lateral mis-registrations of the system while in operation. Aims. For preset and target acquisition, large lateral registration errors must be assessed in open loop to bring the system to a state where the AO loop closes. In closed loop, these errors must be monitored and corrected, without impacting the science. Methods. With respect to the first requirement, our method is perturbative, with two-dimensional modes intentionally applied to the system and correlated to a reference interaction matrix. For the second requirement, we applied a non-perturbative approach that searches for specific patterns in temporal correlations in the closed loop telemetry. This signal is produced by the noise propagation through the AO loop. Results. Our methods were validated through simulations and on the GRAVITY+ development bench. The first method robustly estimates the lateral mis-registrations, in a single fit and with a sub-subaperture resolution while in an open loop. The second method is not absolute, but it does successfully bring the system towards a negligible mis-registration error, with a limited turbulence bias. Both methods proved to robustly work on a system still under development and not fully characterised. Conclusions. Tested with Shack-Hartmann wavefront sensors, the proposed methods are versatile and easily adaptable to other AO instruments, such as the pyramid, which stands as a baseline for all future AO systems. The non-perturbative method, not relying on an interaction matrix model and being sparse in the Fourier domain, is particularly suitable to the next generation of AO systems for extremely large telescopes that will present an unprecedented level of complexity and numbers of actuators.
