Neural Network-based Power Flow Model

Power flow analysis is used to evaluate the flow of electricity in the power system network. Power flow calculation is used to determine the steady-state variables of the system, such as the voltage magnitude /phase angle of each bus and the active/reactive power flow on each branch. The DC power flow model is a popular linear power flow model that is widely used in the power industry. Although it is fast and robust, it may lead to inaccurate line flow results for some critical transmission lines. This drawback can be partially addressed by data-driven methods that take advantage of historical grid profiles. In this paper, a neural network (NN) model is trained to predict power flow results using historical power system data. Although the training process may take time, once trained, it is very fast to estimate line flows. A comprehensive performance analysis between the proposed NN-based power flow model and the traditional DC power flow model is conducted. It can be concluded that the proposed NN-based power flow model can find solutions quickly and more accurately than DC power flow model.
