Neural ODE and DAE Modules for Power System Dynamic Modeling

The time-domain simulation is the fundamental tool for power system transient stability analysis. Accurate and reliable simulations rely on accurate dynamic component modeling. In practical power systems, dynamic component modeling has long faced the challenges of model determination and model calibration, especially with the rapid development of renewable generation and power electronics. In this paper, based on the general framework of neural ordinary differential equations (ODEs), a modified neural ODE module and a neural differential-algebraic equations (DAEs) module for power system dynamic component modeling are proposed. The modules adopt an autoencoder to raise the dimension of state variables, model the dynamics of components with artificial neural networks (ANNs), and keep the numerical integration structure. In the neural DAE module, an additional ANN is used to calculate injection currents. The neural models can be easily integrated into time-domain simulations. With datasets consisting of sampled curves of input variables and output variables, the proposed modules can be used to fulfill the tasks of parameter inference, physics-data-integrated modeling, black-box modeling, etc., and can be easily integrated into power system dynamic simulations. Some simple numerical tests are carried out in the IEEE-39 system and prove the validity and potentiality of the proposed modules.

Exploration of AI-Oriented Power System Transient Stability Simulations

Artificial Intelligence (AI) has made significant progress in the past 5 years and is playing a more and more important role in power system analysis and control. It is foreseeable that the future power system transient stability simulations will be deeply integrated with AI. However, the existing power system dynamic simulation tools are not AI-friendly enough. In this paper, a general design of an AI-oriented power system transient stability simulator is proposed. It is a parallel simulator with a flexible application programming interface so that the simulator has rapid simulation speed, neural network supportability, and network topology accessibility. A prototype of this design is implemented and made public based on our previously realized simulator. Tests of this AI-oriented simulator are carried out under multiple scenarios, which proves that the design and implementation of the simulator are reasonable, AI-friendly, and highly efficient.
