Design of Reward Function on Reinforcement Learning for Automated Driving

This paper proposes a design scheme of reward function that constantly evaluates both driving states and actions for applying reinforcement learning to automated driving. In the field of reinforcement learning, reward functions often evaluate whether the goal is achieved by assigning values such as +1 for success and -1 for failure. This type of reward function can potentially obtain a policy that achieves the goal, but the process by which the goal is reached is not evaluated. However, process to reach a destination is important for automated driving, such as keeping velocity, avoiding risk, retaining distance from other cars, keeping comfortable for passengers. Therefore, the reward function designed by the proposed scheme is suited for automated driving by evaluating driving process. The effects of the proposed scheme are demonstrated on simulated circuit driving and highway cruising. Asynchronous Advantage Actor-Critic is used, and models are trained under some situations for generalization. The result shows that appropriate driving positions are obtained, such as traveling on the inside of corners, and rapid deceleration to turn along sharp curves. In highway cruising, the ego vehicle becomes able to change lane in an environment where there are other vehicles with suitable deceleration to avoid catching up to a front vehicle, and acceleration so that a rear vehicle does not catch up to the ego vehicle.

Speed Optimization Algorithm based on Deterministic Markov Decision Process for Automated Highway Merge

This study presents a robust optimization algorithm for automated highway merge. The merging scenario is one of the challenging scenes in automated driving, because it requires adjusting ego vehicle's speed to match other vehicles before reaching the end point. Then, we model the speed planning problem as a deterministic Markov decision process. The proposed scheme is able to compute each state value of the process and reliably derive the optimal sequence of actions. In our approach, we adopt jerk as the action of the process to prevent a sudden change of acceleration. However, since this expands the state space, we also consider ways to achieve a real-time operation. We compared our scheme with a simple algorithm with the Intelligent Driver Model. We not only evaluated the scheme in a simulation environment but also conduct a real world testing.
