Internal joint forces in dynamics of a 3-PRP planar parallel robot

Recursive matrix relations for the complete dynamics of a 3-PRP planar parallel robot are established in this paper. Three identical planar legs connecting to the moving platform are located in the same vertical plane. Knowing the motion of the platform, we develop first the inverse kinematical problem and determine the positions, velocities and accelerations of the robot. Further, the inverse dynamic problem is solved using an approach based on the principle of virtual work. Finally, some graphs of simulation for the input powers of three actuators and the internal joint forces are obtained.

Dynamics of the Orthoglide parallel robot

Recursive matrix relations for kinematics and dynamics of the Orthoglide parallel robot having three concurrent prismatic actuators are established in this paper. These are arranged according to the Cartesian coordinate system with fixed orientation, which means that the actuating directions are normal to each other. Three identical legs connecting to the moving platform are located on three planes being perpendicular to each other too. Knowing the position and the translation motion of the platform, we develop the inverse kinematics problem and determine the position, velocity and acceleration of each element of the robot. Further, the principle of virtual work is used in the inverse dynamic problem. Some matrix equations offer iterative expressions and graphs for the input forces and the powers of the three actuators.

Kinematics of A 3-PRP planar parallel robot

Recursive modelling for the kinematics of a 3-PRP planar parallel robot is presented in this paper. Three planar chains connecting to the moving platform of the manipulator are located in a vertical plane. Knowing the motion of the platform, we develop the inverse kinematics and determine the positions, velocities and accelerations of the robot. Several matrix equations offer iterative expressions and graphs for the displacements, velocities and accelerations of three prismatic actuators.
