DL-Polycube: Deep learning enhanced polycube method for high-quality hexahedral mesh generation and volumetric spline construction

In this paper, we present a novel algorithm that integrates deep learning with the polycube method (DL-Polycube) to generate high-quality hexahedral (hex) meshes, which are then used to construct volumetric splines for isogeometric analysis. Our DL-Polycube algorithm begins by establishing a connection between surface triangular meshes and polycube structures. We employ deep neural network to classify surface triangular meshes into their corresponding polycube structures. Following this, we combine the acquired polycube structural information with unsupervised learning to perform surface segmentation of triangular meshes. This step addresses the issue of segmentation not corresponding to a polycube while reducing manual intervention. Quality hex meshes are then generated from the polycube structures, with employing octree subdivision, parametric mapping and quality improvement techniques. The incorporation of deep learning for creating polycube structures, combined with unsupervised learning for segmentation of surface triangular meshes, substantially accelerates hex mesh generation. Finally, truncated hierarchical B-splines are constructed on the generated hex meshes. We extract trivariate B\'ezier elements from these splines and apply them directly in isogeometric analysis. We offer several examples to demonstrate the robustness of our DL-Polycube algorithm.

SRL-Assisted AFM: Generating Planar Unstructured Quadrilateral Meshes with Supervised and Reinforcement Learning-Assisted Advancing Front Method

High-quality mesh generation is the foundation of accurate finite element analysis. Due to the vast interior vertices search space and complex initial boundaries, mesh generation for complicated domains requires substantial manual processing and has long been considered the most challenging and time-consuming bottleneck of the entire modeling and analysis process. In this paper, we present a novel computational framework named ``SRL-assisted AFM" for meshing planar geometries by combining the advancing front method with neural networks that select reference vertices and update the front boundary using ``policy networks." These deep neural networks are trained using a unique pipeline that combines supervised learning with reinforcement learning to iteratively improve mesh quality. First, we generate different initial boundaries by randomly sampling points in a square domain and connecting them sequentially. These boundaries are used for obtaining input meshes and extracting training datasets in the supervised learning module. We then iteratively improve the reinforcement learning model performance with reward functions designed for special requirements, such as improving the mesh quality and controlling the number and distribution of extraordinary points. Our proposed supervised learning neural networks achieve an accuracy higher than 98% on predicting commercial software. The final reinforcement learning neural networks automatically generate high-quality quadrilateral meshes for complex planar domains with sharp features and boundary layers.

Generate plane quad mesh with neural networks and tree search

The quality of mesh generation has long been considered a vital aspect in providing engineers with reliable simulation results throughout the history of the Finite Element Method (FEM). The element extraction method, which is currently the most robust method, is used in business software. However, in order to speed up extraction, the approach is done by finding the next element that optimizes a target function, which can result in local mesh of bad quality after many time steps. We provide TreeMesh, a method that uses this method in conjunction with reinforcement learning (also possible with supervised learning) and a novel Monte-Carlo tree search (MCTS) (Coulom(2006), Kocsis and Szepesv\'ari(2006), Browne et~al.(2012)). The algorithm is based on a previously proposed approach (Pan et~al.(2021)). After making many improvements on DRL (algorithm, state-action-reward setting) and adding a MCTS, it outperforms the former work on the same boundary. Furthermore, using tree search, our program reveals much preponderance on seed-density-changing boundaries, which is common on thin-film materials.
