Femtosecond laser fabricated nitinol living hinges for millimeter-sized robots

Nitinol is a smart material that can be used as an actuator, a sensor, or a structural element, and has the potential to significantly enhance the capabilities of microrobots. Femtosecond laser technology can be used to process nitinol while avoiding heat-affected zones (HAZ), thus retaining superelastic properties. In this work, we manufacture living hinges of arbitrary cross-sections from nitinol using a femtosecond laser micromachining process. We first determined the laser cutting parameters, 4.1 Jcm^-2 fluence with 5 passes for 5 um ablation, by varying laser power level and number of passes. Next, we modeled the hinges using an analytical model as well as creating an Abaqus finite element method, and showed the accuracy of the models by comparing them to the torque produced by eight different hinges, four with a rectangular cross-section and four with an arc cross-section. Finally, we manufactured three prototype miniature devices to illustrate the usefulness of these nitinol hinges: a sample spherical 5-bar mechanism, a sarrus linkage, and a piezoelectric actuated robotic wing mechanism.

mCLARI: a shape-morphing insect-scale robot capable of omnidirectional terrain-adaptive locomotion in laterally confined spaces

Soft compliant microrobots have the potential to deliver significant societal impact when deployed in applications such as search and rescue. In this research we present mCLARI, a body compliant quadrupedal microrobot of 20mm neutral body length and 0.97g, improving on its larger predecessor, CLARI. This robot has four independently actuated leg modules with 2 degrees of freedom, each driven by piezoelectric actuators. The legs are interconnected in a closed kinematic chain via passive body joints, enabling passive body compliance for shape adaptation to external constraints. Despite scaling its larger predecessor down to 60 percent in length and 38 percent in mass, mCLARI maintains 80 percent of the actuation power to achieve high agility. Additionally, we demonstrate the new capability of passively shape-morphing mCLARI - omnidirectional laterally confined locomotion - and experimentally quantify its running performance achieving a new unconstrained top speed of 3 bodylengths/s (60 mms-1). Leveraging passive body compliance, mCLARI can navigate through narrow spaces with a body compression ratio of up to 1.5x the neutral body shape.
