Walking, Rolling, and Beyond: First-Principles and RL Locomotion on a TARS-Inspired Robot

Robotic locomotion research typically draws from biologically inspired leg designs, yet many human-engineered settings can benefit from non-anthropomorphic forms. TARS3D translates the block-shaped 'TARS' robot from Interstellar into a 0.25 m, 0.99 kg research platform with seven actuated degrees of freedom. The film shows two primary gaits: a bipedal-like walk and a high-speed rolling mode. For TARS3D, we build reduced-order models for each, derive closed-form limit-cycle conditions, and validate the predictions on hardware. Experiments confirm that the robot respects its +/-150 degree hip limits, alternates left-right contacts without interference, and maintains an eight-step hybrid limit cycle in rolling mode. Because each telescopic leg provides four contact corners, the rolling gait is modeled as an eight-spoke double rimless wheel. The robot's telescopic leg redundancy implies a far richer gait repertoire than the two limit cycles treated analytically. So, we used deep reinforcement learning (DRL) in simulation to search the unexplored space. We observed that the learned policy can recover the analytic gaits under the right priors and discover novel behaviors as well. Our findings show that TARS3D's fiction-inspired bio-transcending morphology can realize multiple previously unexplored locomotion modes and that further learning-driven search is likely to reveal more. This combination of analytic synthesis and reinforcement learning opens a promising pathway for multimodal robotics.

Teleoperation of a Humanoid Robot with Motion Imitation and Legged Locomotion

This work presents a teleoperated humanoid robot system that can imitate human motions, walk and turn. To capture human motions, a Microsoft Kinect Depth sensor is used. Unlike the cumbersome motion capture suits, the sensor makes the system more comfortable to interact with. The skeleton data is extracted from the Kinect which is processed to generate the robot's joint angles. Robot Operating System (ROS) is used for the communication between the various parts of the code to achieve minimal latency. Thus the robot imitates the human in real-time with negligible lag. Unlike most of the human motion imitation systems, this system is not stationary. The lower body motions of the user are captured and processed and used to make the robot walk forward, backward and to make it turn right or left thus enabling a completely dynamic teleoperated humanoid robot system.
