On the Hyperparameter Landscapes of Machine Learning Algorithms

Despite the recent success in a plethora of hyperparameter optimization (HPO) methods for machine learning (ML) models, the intricate interplay between model hyperparameters (HPs) and predictive losses (a.k.a fitness), which is a key prerequisite for understanding HPO, remain notably underexplored in our community. This results in limited explainability in the HPO process, rendering a lack of human trust and difficulties in pinpointing algorithm bottlenecks. In this paper, we aim to shed light on this black box by conducting large-scale fitness landscape analysis (FLA) on 1,500 HP loss landscapes of 6 ML models with more than 11 model configurations, across 67 datasets and different levels of fidelities. We reveal the first unified, comprehensive portrait of their topographies in terms of smoothness, neutrality and modality. We also show that such properties are highly transferable across datasets and fidelities, providing fundamental evidence for the success of multi-fidelity and transfer learning methods. These findings are made possible by developing a dedicated FLA framework that incorporates a combination of visual and quantitative measures. We further demonstrate the potential of this framework by analyzing the NAS-Bench-101 landscape, and we believe it is able to faciliate fundamental understanding of a broader range of AutoML tasks.
