Distortion Mitigation in Millimeter-Wave Interferometric Radar Angular Velocity Estimation Using Signal Response Decomposition

A new method of distortion mitigation for multitarget interferometric angular velocity estimation in millimeter-wave radar is presented. In general, when multiple targets are present, the response of a correlation interferometer is corrupted by intermodulation distortion, making it difficult to estimate individual target angular velocities. We present a distortion mitigation method that works by decomposing the responses at each antenna element into the responses from the individual targets. Data association is performed to match individual target responses at each antenna such that cross-correlation is performed only between associated targets. Thus, the intermodulation distortion (cross-terms) from correlating unlike targets are eliminated, and the result is a frequency response whose individual frequencies are proportional to the angular velocities of the targets. We demonstrate the approach with a custom 40 GHz interferometric radar, a high-accuracy motion capture system which provides ground-truth position measurements, and two robotic platforms. The multitarget experiments consist of three scenarios, designed to represent easy, medium, and difficult cases for the distortion mitigation technique. We show that the reduction in distortion yields angular velocity estimation errors in the three cases of less than $0.008$ rad/s, $0.020$ rad/s, and $0.033$ rad/s for the easy, medium, and hard cases, respectively.
