Coherent FDA Receiver and Joint Range-Space-Time Processing

When a target is masked by mainlobe clutter with the same Doppler frequency, it is difficult for conventional airborne radars to determine whether a target is present in a given observation using regular space-time adaptive processing techniques. Different from phased-array and multiple-input multiple-output (MIMO) arrays, frequency diverse arrays (FDAs) employ frequency offsets across the array elements, delivering additional range-controllable degrees of freedom, potentially enabling suppression for this kind of clutter. However, the reception of coherent FDA systems employing small frequency offsets and achieving high transmit gain can be further improved. To this end, this work proposes an coherent airborne FDA radar receiver that explores the orthogonality of echo signals in the Doppler domain, allowing a joint space-time processing module to be deployed to separate the aliased returns. The resulting range-space-time adaptive processing allows for a preferable detection performance for coherent airborne FDA radars as compared to current alternative techniques.

FDA Beampattern Characteristics With Considering Time-Range Relations

Existing investigations show that frequency diverse array (FDA) will produce angle-range-dependent and time-variant transmit beampattern, but the relations between time and range and their characteristics still are not fully investigated. In order to fully exploit the time and range dependent characteristics of FDA transmit beampattern and address the effects of FDA frequency offsets, we systematically reformulate the FDA antenna and system model with specific time-range relation consideration. Two FDA transmit beampatterns, namely, instantaneous and integral ones, are derived. Accordingly, the FDA time and range dependent characteristics together with the comparisons to conventional phased-array and co-located multiple-input multiple-output (MIMO) antennas are analyzed. Both theoretical analysis and simulation results reveal that the FDA time-range dependent characteristics actually can be regarded as auto-scanning capability, which may provide many promising applications.

Coherent FDA Radar Systems: Joint Design of Transmitting and Receiving Array Weighters

Due to the frequency offset across its array elements, frequency diverse array (FDA) will generate angle-range-dependent and time-variant transmit beampattern. Since existing investigations usually focus on FDA transmitter and only instantaneous beampattern is considered, which cannot fully exploit the time-range characteristics of FDA radar for enhanced performance, in this paper we formulate a multi-carrier mixing receiver for coherent pulsed-Doppler FDA radar to effectively retain the range information of FDA radar returned signals in subsequent receiver processing. Accordingly, the joint transmitter and receiver is systematically modeled with time-range relationship consideration. More importantly, we optimally design the joint transmitting and receiving weighters by maximizing the radiated energy within the desired range-angle sections for given total energy. All proposed methods are verified by simulation results.

Designing FDA Radars Robust to Contaminated Shared Spectra

This paper considers the problem of jointly designing the transmit waveforms and weights for a frequency diverse array (FDA) in a spectrally congested environment in which unintentional spectral interferences exist. Exploiting the properties of the interference signal induced by the processing of the multi-channel mixing and low-pass filtering FDA receiver, the interference covariance matrix structure is derived. With this, the receive weights are formed using the minimum variance distortionless response (MVDR) method for interference cancellation. Owing to the fact that the resulting output signal-to-interference-plus-noise ratio (SINR) is a function of the transmit waveforms and weights, as well as due to the ever-greater competition for the finite available spectrum, a joint design scheme for the FDA transmit weights and the spectrally compatible waveforms is proposed to efficiently use the available spectrum while maintaining a sufficient receive SINR. The performance of the proposed technique is verified using numerical simulations in terms of the achievable SINR, spectral compatiblity, as well as several aspects of the synthesized waveforms.

Waveform Optimization with SINR Criteria for FDA Radar in the Presence of Signal-Dependent Mainlobe Interference

In this paper, we focus on the design of the transmit waveforms of a frequency diverse array (FDA) in order to improve the output signal-to-interference-plus-noise ratio (SINR) in the presence of signal-dependent mainlobe interference. Since the classical multi-carrier matched filtering-based FDA receiver cannot effectively utilize the waveform diversity of FDA, a novel FDA receiver framework based on multi-channel mixing and low-pass filtering is developed to keep the separation of the transmit waveform at the receiver side, while preserving the FDA range-controllable degrees of freedom. Furthermore, a range-angle minimum variance distortionless response beamforming technique is introduced to synthesize receiver filter weights with the ability to suppress a possible signal-dependent mainlobe interference. The resulting FDA transmit waveform design problem is initially formulated as an optimization problem consisting of a non-convex objective function and multiple non-convex constraints. To efficiently slove this, we introduce two algorithms, one based on a signal relaxation technique, and the other based on the majorization minimization technique. The preferable performance of the proposed multi-channel low-pass filtering receiver and the optimized transmit waveforms is illustrated using numerical simulations, indicating that the resulting FDA system is not only able to effectively suppress mainlobe interference, but also to yield estimates with a higher SINR than the FDA system without waveform optimization.
