Physical Modelling and Cancellation of External Passive Intermodulation in FDD MIMO

In this paper, the physical approach to model external (air-induced) passive intermodulation (PIM) is presented in a frequency-division duplexing (FDD) multiple-input multiple-output (MIMO) system with an arbitrary number of transceiver chains. The external PIM is a special case of intermodulation distortion (IMD), mainly generated by metallic objects possessing nonlinear properties ("rusty bolt" effect). Typically, such sources are located in the near-field or transition region of the antenna array. PIM products may fall into the receiver band of the FDD system, negatively affecting the uplink signal. In contrast to other works, this one directly simulates the physical external PIM. The system includes models of a point-source external PIM, a finite-length dipole antenna, a MIMO antenna array, and a baseband multicarrier 5G NR OFDM signal. The Channel coefficients method for multi-PIM-source compensation is replicated to verify the proposed external PIM modelling approach. Simulation results of artificially generated PIM cancellation show similar performance as real-life experiments. Therefore, the proposed approach allows testing PIM compensation algorithms on large systems with many antennas and arbitrary array structures. This eliminates the need for experiments with real hardware at the development stage of the PIM cancellation algorithm.

Scaling transformation of the multimode nonlinear Schrödinger equation for physics-informed neural networks

Single-mode optical fibers (SMFs) have become the backbone of modern communication systems. However, their throughput is expected to reach its theoretical limit in the nearest future. Utilization of multimode fibers (MMFs) is considered as one of the most promising solutions rectifying this capacity crunch. Nevertheless, differential equations describing light propagation in MMFs are a way more sophisticated than those for SMFs, which makes numerical modelling of MMF-based systems computationally demanding and impractical for the most part of realistic scenarios. Physics-informed neural networks (PINNs) are known to outperform conventional numerical approaches in various domains and have been successfully applied to the nonlinear Schr\"odinger equation (NLSE) describing light propagation in SMFs. A comprehensive study on application of PINN to the multimode NLSE (MMNLSE) is still lacking though. To the best of our knowledge, this paper is the first to deploy the paradigm of PINN for MMNLSE and to demonstrate that a straightforward implementation of PINNs by analogy with NLSE does not work out. We pinpoint all issues hindering PINN convergence and introduce a novel scaling transformation for the zero-order dispersion coefficient that makes PINN capture all relevant physical effects. Our simulations reveal good agreement with the split-step Fourier (SSF) method and extend numerically attainable propagation lengths up to several hundred meters. All major limitations are also highlighted.
