2D and 3D Vascular Structures Enhancement via Multiscale Fractional Anisotropy Tensor

The detection of vascular structures from noisy images is a fundamental process for extracting meaningful information in many applications. Most well-known vascular enhancing techniques often rely on Hessian-based filters. This paper investigates the feasibility and deficiencies of detecting curve-like structures using a Hessian matrix. The main contribution is a novel enhancement function, which overcomes the deficiencies of established methods. Our approach has been evaluated quantitatively and qualitatively using synthetic examples and a wide range of real 2D and 3D biomedical images. Compared with other existing approaches, the experimental results prove that our proposed approach achieves high-quality curvilinear structure enhancement.

Curvilinear Structure Enhancement by Multiscale Top-Hat Tensor in 2D/3D Images

A wide range of biomedical applications requires enhancement, detection, quantification and modelling of curvilinear structures in 2D and 3D images. Curvilinear structure enhancement is a crucial step for further analysis, but many of the enhancement approaches still suffer from contrast variations and noise. This can be addressed using a multiscale approach that produces a better quality enhancement for low contrast and noisy images compared with a single-scale approach in a wide range of biomedical images. Here, we propose the Multiscale Top-Hat Tensor (MTHT) approach, which combines multiscale morphological filtering with a local tensor representation of curvilinear structures in 2D and 3D images. The proposed approach is validated on synthetic and real data and is also compared to the state-of-the-art approaches. Our results show that the proposed approach achieves high-quality curvilinear structure enhancement in synthetic examples and in a wide range of 2D and 3D images.
