Influence of segmentation accuracy in structural MR head scans on electric field computation for TMS and tES

In several diagnosis and therapy procedures based on electrostimulation effect, the internal physical quantity related to the stimulation is the induced electric field. To estimate the induced electric field in an individual human model, the segmentation of anatomical imaging, such as (magnetic resonance image (MRI) scans, of the corresponding body parts into tissues is required. Then, electrical properties associated with different annotated tissues are assigned to the digital model to generate a volume conductor. An open question is how segmentation accuracy of different tissues would influence the distribution of the induced electric field. In this study, we applied parametric segmentation of different tissues to exploit the segmentation of available MRI to generate different quality of head models using deep learning neural network architecture, named ForkNet. Then, the induced electric field are compared to assess the effect of model segmentation variations. Computational results indicate that the influence of segmentation error is tissue-dependent. In brain, sensitivity to segmentation accuracy is relatively high in cerebrospinal fluid (CSF), moderate in gray matter (GM) and low in white matter for transcranial magnetic stimulation (TMS) and transcranial electrical stimulation (tES). A CSF segmentation accuracy reduction of 10% in terms of Dice coefficient (DC) lead to decrease up to 4% in normalized induced electric field in both applications. However, a GM segmentation accuracy reduction of 5.6% DC leads to increase of normalized induced electric field up to 6%. Opposite trend of electric field variation was found between CSF and GM for both TMS and tES. The finding obtained here would be useful to quantify potential uncertainty of computational results.

Development of accurate human head models for personalized electromagnetic dosimetry using deep learning

The development of personalized human head models from medical images has become an important topic in the electromagnetic dosimetry field, including the optimization of electrostimulation, safety assessments, etc. Human head models are commonly generated via the segmentation of magnetic resonance images into different anatomical tissues. This process is time consuming and requires special experience for segmenting a relatively large number of tissues. Thus, it is challenging to accurately compute the electric field in different specific brain regions. Recently, deep learning has been applied for the segmentation of the human brain. However, most studies have focused on the segmentation of brain tissue only and little attention has been paid to other tissues, which are considerably important for electromagnetic dosimetry. In this study, we propose a new architecture for a convolutional neural network, named ForkNet, to perform the segmentation of whole human head structures, which is essential for evaluating the electrical field distribution in the brain. The proposed network can be used to generate personalized head models and applied for the evaluation of the electric field in the brain during transcranial magnetic stimulation. Our computational results indicate that the head models generated using the proposed network exhibit strong matching with those created via manual segmentation in an intra-scanner segmentation task.

End-to-end semantic segmentation of personalized deep brain structures for non-invasive brain stimulation

Electro-stimulation or modulation of deep brain regions is commonly used in clinical procedures for the treatment of several nervous system disorders. In particular, transcranial direct current stimulation (tDCS) is widely used as an affordable clinical application that is applied through electrodes attached to the scalp. However, it is difficult to determine the amount and distribution of the electric field (EF) in the different brain regions due to anatomical complexity and high inter-subject variability. Personalized tDCS is an emerging clinical procedure that is used to tolerate electrode montage for accurate targeting. This procedure is guided by computational head models generated from anatomical images such as MRI. Distribution of the EF in segmented head models can be calculated through simulation studies. Therefore, fast, accurate, and feasible segmentation of different brain structures would lead to a better adjustment for customized tDCS studies. In this study, a single-encoder multi-decoders convolutional neural network is proposed for deep brain segmentation. The proposed architecture is trained to segment seven deep brain structures using T1-weighted MRI. Network generated models are compared with a reference model constructed using a semi-automatic method, and it presents a high matching especially in Thalamus (Dice Coefficient (DC) = 94.70%), Caudate (DC = 91.98%) and Putamen (DC = 90.31%) structures. Electric field distribution during tDCS in generated and reference models matched well each other, suggesting its potential usefulness in clinical practice.

Non-Uniform Conductivity Estimation for Personalized Brain Stimulation using Deep Learning

Electromagnetic stimulation of the human brain is a key tool for the neurophysiological characterization and diagnosis of several neurological disorders. Transcranial magnetic stimulation (TMS) is one procedure that is commonly used clinically. However, personalized TMS requires a pipeline for accurate head model generation to provide target-specific stimulation. This process includes intensive segmentation of several head tissues based on magnetic resonance imaging (MRI), which has significant potential for segmentation error, especially for low-contrast tissues. Additionally, a uniform electrical conductivity is assigned to each tissue in the model, which is an unrealistic assumption based on conventional volume conductor modeling. This paper proposes a novel approach to the automatic estimation of electric conductivity in the human head for volume conductor models without anatomical segmentation. A convolutional neural network is designed to estimate personalized electrical conductivity values based on anatomical information obtained from T1- and T2-weighted MRI scans. This approach can avoid the time-consuming process of tissue segmentation and maximize the advantages of position-dependent conductivity assignment based on water content values estimated from MRI intensity values. The computational results of the proposed approach provide similar but smoother electric field results for the brain when compared to conventional approaches.
