Learning test generators for cyber-physical systems

Black-box runtime verification methods for cyber-physical systems can be used to discover errors in systems whose inputs and outputs are expressed as signals over time and their correctness requirements are specified in a temporal logic. Existing methods, such as requirement falsification, often focus on finding a single input that is a counterexample to system correctness. In this paper, we study how to create test generators that can produce multiple and diverse counterexamples for a single requirement. Several counterexamples expose system failures in varying input conditions and support the root cause analysis of the faults. We present the WOGAN algorithm to create such test generators automatically. The algorithm works by training iteratively a Wasserstein generative adversarial network that models the target distribution of the uniform distribution on the set of counterexamples. WOGAN is an algorithm that trains generative models that act as test generators for runtime verification. The training is performed online without the need for a previous model or dataset. We also propose criteria to evaluate such test generators. We evaluate the trained generators on several well-known problems including the ARCH-COMP falsification benchmarks. Our experimental results indicate that generators trained by the WOGAN algorithm are as effective as state-of-the-art requirement falsification algorithms while producing tests that are as diverse as a sample from uniform random sampling. We conclude that WOGAN is a viable method to produce test generators automatically and that these test generators can generate multiple and diverse counterexamples for the runtime verification of cyber-physical systems.

Requirement falsification for cyber-physical systems using generative models

We present the OGAN algorithm for automatic requirement falsification of cyber-physical systems. System inputs and output are represented as piecewise constant signals over time while requirements are expressed in signal temporal logic. OGAN can find inputs that are counterexamples for the safety of a system revealing design, software, or hardware defects before the system is taken into operation. The OGAN algorithm works by training a generative machine learning model to produce such counterexamples. It executes tests atomically and does not require any previous model of the system under test. We evaluate OGAN using the ARCH-COMP benchmark problems, and the experimental results show that generative models are a viable method for requirement falsification. OGAN can be applied to new systems with little effort, has few requirements for the system under test, and exhibits state-of-the-art CPS falsification efficiency and effectiveness.

WOGAN at the SBST 2022 CPS Tool Competition

WOGAN is an online test generation algorithm based on Wasserstein generative adversarial networks. In this note, we present how WOGAN works and summarize its performance in the SBST 2022 CPS tool competition concerning the AI of a self-driving car.

Wasserstein Generative Adversarial Networks for Online Test Generation for Cyber Physical Systems

We propose a novel online test generation algorithm WOGAN based on Wasserstein Generative Adversarial Networks. WOGAN is a general-purpose black-box test generator applicable to any system under test having a fitness function for determining failing tests. As a proof of concept, we evaluate WOGAN by generating roads such that a lane assistance system of a car fails to stay on the designated lane. We find that our algorithm has a competitive performance respect to previously published algorithms.

Falsification of Multiple Requirements for Cyber-Physical Systems Using Online Generative Adversarial Networks and Multi-Armed Bandits

We consider the problem of falsifying safety requirements of Cyber-Physical Systems expressed in signal temporal logic (STL). This problem can be turned into an optimization problem via STL robustness functions. In this paper, our focus is in falsifying systems with multiple requirements. We propose to solve such conjunctive requirements using online generative adversarial networks (GANs) as test generators. Our main contribution is an algorithm which falsifies a conjunctive requirement $\varphi_1 \land \cdots \land \varphi_n$ by using a GAN for each requirement $\varphi_i$ separately. Using ideas from multi-armed bandit algorithms, our algorithm only trains a single GAN at every step, which saves resources. Our experiments indicate that, in addition to saving resources, this multi-armed bandit algorithm can falsify requirements with fewer number of executions on the system under test when compared to (i) an algorithm training a single GAN for the complete conjunctive requirement and (ii) an algorithm always training $n$ GANs at each step.
