Time-Reflection of Microwaves by a Fast Optically-Controlled Time-Boundary

When an electromagnetic (EM) wave is propagating in a medium whose properties are varied abruptly in time, the wave experiences refractions and reflections known as "time-refractions" and "time-reflections", both manifesting spectral translation as a consequence of the abrupt change of the medium and the conservation of momentum. However, while the time-refracted wave continues to propagate with the same wave-vector, the time-reflected wave is propagating backward with a conjugate phase, despite the lack of any spatial interface. Importantly, while time-refraction is always significant, observing time-reflection poses a major challenge - because it requires a large change in the medium occurring within a single cycle. For that reason, time-reflection of EM waves was observed only recently. Here, we present the observation of microwave pulses at the highest frequency ever observed (0.59 GHz), and the experimental evidence of the phase-conjugation nature of time-reflected waves. Our experiments are carried out in a periodically-loaded microstrip line with optically-controlled picosecond-switchable photodiodes. Our system paves the way to the experimental realization of Photonic Time-Crystals at GHz frequencies.

Multi-Octave Interference Detectors with Sub-Microsecond Response

High-power interferers are one of the main hurdles in wideband communication channels. To that end, this paper presents a wideband interferer detection method. The presented technique operates by sampling the incoming signal as an input, and produces the frequency and the power readings of the detected interferer. The detection method relies on driving an open circuit stub, where the voltage is proportional to the power of the interferer, and the standing wave pattern is an indicator of its frequency. This approach is feasible over multi-octave bandwidth with a wide power dynamic range. The concept is analyzed for design and optimization, and a prototype is built for a proof-of-concept. The measured results demonstrate the ability to detect an interferer within the 1--16 GHz frequency range, with a power dynamic range between -20 to 20 dBm. The detection concept is also fitted with different types of tunable bandstop filters (BSFs) for automatic detection and suppression of the interferer if its power exceeds a programmable threshold. With a measured response time of 500 ns, the presented method is a technology enabler for wideband receivers.
